Dry insulated GIS terminal DH-YJZGG for XLPE insulated power cable //

Dry insulated (transformer) oil-immersed terminal DH-YJZYG for XLPE insulated power cable

 Electric field stress control uses stress cones, and is made of imported silicone rubber, presenting excellent electrical insulation performance.

In a compact overall structure design, the pressure to the contact surface between the stress cone and the inner wall of the epoxy sleeve is maintained with a spring mechanical device.

Fully dry structure section, no need to fill insulating oil or gas inside.

Cable terminals can be connected to the equipment horizontally, vertically, or at any other angle.

The cable is isolated from the equipment cable compartment by epoxy sleeve, which avoids the need to open the cable compartment on-site for installation or maintenance operation and reduces much handling of insulating oil or gas.

Shielding ring is optional for (transformer) oil-immersed terminal.
