Modular prefabricated rubber insulating part straight joint DH-YJJTZ for XLPE insulated power cable□ //

Modular prefabricated rubber insulating part insulated joint DH-YJJJZ for XLPE insulated power cable□

Electric field stress control uses stress cones, and is made of imported silicone rubber, presenting excellent electrical insulation performance.

The main body of this joint is formed by vacuum casting of epoxy resin, which is waterproof, moisture-proof and corrosion-resistant.

The joint can be used to connect cables with the same or different cross-sections at both ends. The cables at both ends are spatially independent, and the cable conductors are connected to the fittings in a plug-in and press-free structure.

When installing, simply insert the pretreated cables in at both ends with ease.

The outer layer of the joint contains a protective enclosure and a waterproof insulating sealing structure, which presents good mechanical protection, sealing and anti-corrosion performance, ensuring the safe operation of the joint in long-term harsh environments.
